Drilling Tool, CoroDrill, 880-D1700L20-03SANDVIK COROMANT
Original
brand： SANDVIK COROMANT
Series： CoroDrill 880
Diameter： 17mm
Drilling Depth： 51mm
price： 面议
minimum： 1 pcs
Total supply： 132 pcs
Delivery term： The date of payment from buyers 1 Deliver within days
seat： Asia-Pacific China
Validity to： Long-term effective
Last update： 2015-06-16 08:24
Browse the number： 1254
inquiry
Company Profile


Product details
DrillingTool, CoroDrill, 880-D1700L20-03SANDVIK COROMANTSANDVIK COROMANT

Technical Specs

  • Item  Indexable Drill
  • Series  CoroDrill 880
  • Diameter  17mm
  • Drilling Depth  51mm
  • Ratio  3mm x Dia.
  • Number of Inserts Required  2
  • Inscribed Circle  03
  • Overall Length  119mm
  • Cutting Direction  Right
  • Shank Type  Flat According to ISO 9766
  • Shank Dia.  20mm
  • Shank Length  1.969"
  • ANSI Number  880-D1700L20-03
  • For Use With  880-03 03 W05H-P-GM,880-03 03 W06H-P-GR,880-03 03 W06H-P-LM
