SANDVIK COROMANT General Turning Tool, DCLNR 24 4D

Original

brand：	SANDVIK COROMANT
Type：	Shank Holders
For Use With：	CNMG 432
Nomenclature：	DCLNR244D
price：	271.50元/pcs
minimum：	1 pcs
Total supply：	642 pcs
Delivery term：	The date of payment from buyers 1 Deliver within days
seat：	Asia-Pacific China
Validity to：	Long-term effective
Last update：	2017-12-19 14:26
Browse the number：	790

Company Profile

JINAN TERRY CNC TOOL LIMITED COMPANY
Validated [Credit]
Contact: laura liu(Ms.)
Member: [Offline] [Add Partner]
[Send Message]
E-mail:
Tel:
Mobile:
Area: Asia-Pacific-China
Address: 701, Zone D, Hardware Electrical And Mechanical Market, No. 198, Lishan North Road, Tianqiao District

Product details

SANDVIK COROMANT GeneralTurningTool, DCLNR244D

Technical Specs

Item General Turning Tool
Type Shank Holders
For Use With CNMG 432
Nomenclature DCLNR244D
Style CoroTurn RC
Rake Negative
Rake Angle (Deg.) -5
Left/Right Hand R
Shank Width (In.) 1.5
Shank Square

Shank Height (In.) 1.5
Insert Shape 80 Degrees Diamond
Inscribed Circle (In.) 0.5
Insert Thickness (In.) 0.1875
Clamp 5412028-021
Shim 5322234-01
Dimension F1 (In.) 2
Dimension H1 (In.) 1.5
Dimension L3 (In.) 1.26
