Technical Specs
- Item General Turning Tool
- Type Shank Holders
- For Use With DCMT 3(2.5)2
- Nomenclature SDJCL083C-S
- Style CoroTurn 107
- Rake Neutral
- Rake Angle (Deg.) -3
- Left/Right Hand L
- Shank Width (In.) 0.5
- Shank Square
- Shank Height (In.) 0.5
- Insert Shape 55 Degrees Diamond
- Inscribed Circle (In.) 0.375
- Insert Thickness (In.) 0.1563
- Clamp Screw 5513020-09
- Dimension F1 (In.) 0.5
- Dimension H1 (In.) 0.5
- Dimension L3 (In.) 0.94
