SANDVIK COROMANT GeneralTurningTool, DTFNR123B
Technical Specs
- Item General Turning Tool
- Type Shank Holders
- For Use With TNMG 332
- Nomenclature DTFNR123B
- Style CoroTurn RC
- Lock Floating Wedge Clamping
- Rake Negative
- Rake Angle (Deg.) -1
- Left/Right Hand Right Hand
- Shank Width (In.) 0.75
- Shank Square
- Shank Height (In.) 0.75
- Overall Length (In.) 4.5
- Insert Shape Triangular
- Inscribed Circle (In.) 0.375
- Insert Thickness (In.) 0.1875
- Clamp 5412028-011
- Shim 5322315-02
- Shim Screw 5513020-04
- Dimension F1 (In.) 1
- Dimension H1 (In.) 0.75
- Dimension L3 (In.) 0.933
-
